LOCAL CONSTRUCTION PREVIEW
The blueprint makes placement understandable before it becomes shared state
The blueprint tool starts with camera targeting and a local rectangle. For every covered column, the browser finds the highest opaque voxel, requires the same ground height, rejects fluid or non-solid support, and checks ten voxels of clearance. A valid selection becomes a translucent foundation hologram; a selected NCM3 design is parsed and previewed at one world voxel per design voxel, normally through the building worker with a main-thread fallback when Worker support is unavailable.
Rotation is restricted to quarter turns, X and Z offsets remain integers, and a building that extends beyond the rectangle stays previewable but cannot be submitted. Confirm locks the current valid hologram and begins the chain workflow. These checks keep construction legible and avoid obvious bad transactions, but the Building Program does not read the rendered scene, regenerated terrain, or local clearance scan.
Rotation and offsets are allowed; scaling is not.
The browser rejects local obstructions above the selected support surface.
The hologram remains visually distinct and never enters finalized collision.
BUILDSITE AND CHUNK INDEXES
One protected rectangle is registered everywhere it crosses
A BuildSite PDA binds one owner, global configuration, nonzero foundation ID, fixed minimum X and Z, surface Y, width, depth, revision counters, and indexing progress. The Building Program invokes the Chunk Program through a PDA authority to register the same rectangle in every intersected 16 × 16 Chunk. Only after all entries exist does the BuildSite switch from indexing to active.
Chunk indexes reject a different foundation whose XZ rectangle overlaps an existing one. The overlap rule is two-dimensional, so placing a second foundation at another height does not bypass the reservation. The protected mining layer is narrower: a coordinate is protected only when its XZ position lies inside the rectangle and its Y equals surfaceY minus one. The space above is not an immutable column.
Resize uses staged geometry and a second revision-safe index cycle. Expansion adds new Chunk entries before switching the active rectangle; shrinking removes entries that fall outside only after the new geometry is ready. The fixed anchor never drifts, and an active building must still fit before a shrink can complete.
DECLARATIVE BUILDING FORMAT
NCM3 describes a bounded building without executing imported code
NCM3 is a compact declarative byte format. It declares dimensions and a bounded sequence of material-bearing construction commands such as boxes, repeats, roof families, trees, and fences. The parser expands those commands into canonical material voxels; it does not evaluate JavaScript or download executable building behavior.
The deployed validator accepts at most 256 voxels on each axis, 4,096 commands, and a total expansion budget of 262,144 operations. It rejects noncanonical or overflowing varints, out-of-bounds command geometry, invalid repeat steps, trailing bytes, and material IDs outside the canonical building allowlist. That bounded envelope makes a compact payload predictable enough to validate and reconstruct without storing a raw dense cube.
The manifest rejects zero length or any larger raw NCM3 payload.
Every command must remain within the declared envelope.
Repeated and procedural commands contribute their bounded expanded work.
ON-CHAIN BUILDING COMMIT
Upload is resumable; activation waits for every byte and every check
Beginning a building revision creates a 160-byte BuildingManifest PDA in uploading state and reserves the next BuildSite revision. The manifest stores owner, global configuration, foundation ID, revision, quarter turns, signed offsets, payload length, expected 32-byte hash, shard count, completion bitmap, and slots. Payload capacity is divided into at most eight BuildingShard PDAs of at most 8,192 bytes each.
Shard writes are sequential and limited to 700 payload bytes per instruction. A dropped wallet request can resume from the shard's uploaded length instead of restarting the entire design. Finalization requires every shard account in exact order, validates every PDA and completed length, reconstructs the ordered payload slices, recomputes SHA-256, parses NCM3, checks footprint and height, then activates both manifest and BuildSite revision in one atomic transaction.
The instruction has no backpack or material input accounts. It proves that authorized bytes form an allowed building and fit the protected rectangle; it does not prove that the owner collected or consumed the wood, stone, or glass represented by those material IDs.
The 65,535-byte payload ceiling fits within the bounded shard set.
Sequential offsets make partially uploaded shards safely resumable.
The program hashes the complete ordered raw NCM3 payload before activation.
REGIONAL DISCOVERY BOUNDARY
Guardian records find nearby buildings without replacing their source of truth
A Guardian region account commits a compact regional manifest summary. For the current NCKBRG03 format, it is the first 16 bytes of a SHA-256 digest over the canonical record bytes, plus revision and record count. The client fetches the matching HTTP manifest, recomputes that truncated digest, and rejects a manifest for another region. New or changed records are checked against direct BuildSite PDA geometry, active revision, and updated slot. The BuildSite supplies the authoritative owner, which the loaded BuildingManifest must also match.
Each digest-committed regional record carries the first 16 bytes of one building content hash. The chain loader fetches the active BuildingManifest and every shard, verifies the complete 32-byte payload hash, and requires it to begin with that regional record prefix. Chunk.js then parses the verified NCM3 payload during reconstruction. Guardian discovery can reduce wide account scans and seed a verified cache, but it cannot invent geometry or authorize an uncommitted revision.
When Guardian coverage or a regional manifest is unavailable, the current nearby discovery path does not treat unknown non-owned buildings as trusted. A player's owned BuildSite PDAs can still be restored in one batch. Already verified cached buildings remain visible across temporary RPC failures; building sync waits five seconds before retrying a failure, while an unchanged healthy view uses a 60-second refresh window.
HIGH-PERFORMANCE RECONSTRUCTION
Chunk.js turns a verified payload into light, meshes, and collision once
Chunk.js normally sends NCM3 parsing, placement, baked light, and greedy meshing to a dedicated worker; when Worker support is unavailable, the same deterministic operations fall back to the main thread. Placement preserves exact voxel scale, partitions output by canonical 16 × 16 world columns, removes hidden faces even across building Chunk boundaries, and separates opaque from glass or other visual materials. Packed vertices use a 20-byte stride, while collision occupies a compact Uint32Array bit mask instead of a second object per voxel.
Verified chain buildings are scheduled nearest first. Unchanged foundation, revision, hash, rotation, offset, and placement keys reuse previously built mesh data. A new snapshot cancels stale work and discards a replacement whose decode or meshing fails. The desktop cache is capped by both 64 entries and 48 MiB; the current mobile configuration is capped by both 16 entries and 16 MiB. Frustum bounds keep off-screen building Chunks out of the draw list.
Only finalized chain buildings enter the supplemental collision provider, so a player can stand on a building floor and cannot walk through its solid voxels. A local translucent preview neither writes depth nor becomes authoritative collision. Natural support-collapse planning remains a separate conservative terrain-mining feature; it does not simulate building loads, and the Building Program does not validate a structural support graph.
SPATIAL AND PLACEMENT MATH
One rectangle determines index work; one exact footprint determines acceptance
The first equation mirrors the 16-voxel Chunk coverage used by the Building Program, including negative coordinates. The second shows the centered placement, quarter-turn swap, signed offsets, and height limit checked when a revision is finalized.
Foundation coverage across canonical Chunks
cx0 = div_euclid(minX, 16); cx1 = div_euclid(minX + width - 1, 16); cz0 = div_euclid(minZ, 16); cz1 = div_euclid(minZ + depth - 1, 16); N_index = (cx1 - cx0 + 1)(cz1 - cz0 + 1); T_upsert = ceil(N_index / 4); T_cleanup = ceil(N_removed / 4)Euclidean division keeps coverage correct on both sides of world zero. The program indexes every intersected Chunk in stable row-major order, and the current client submits at most four index steps per transaction. T_upsert describes the indexing phase after creation or resize; it excludes the separate BuildSite transaction. T_cleanup applies only when a shrink leaves old covered Chunks to remove.
- cx0, cx1
- Inclusive minimum and maximum Chunk X coordinates covered by the foundation rectangle.
- cz0, cz1
- Inclusive minimum and maximum Chunk Z coordinates covered by the foundation rectangle.
- N_index
- Number of canonical Chunk index entries required by the BuildSite.
- T_upsert
- Minimum current four-step transactions for the new or staged rectangle's upsert phase.
- T_cleanup
- Minimum current four-step cleanup transactions for N_removed old Chunks left by a shrink.
Exact-scale rotated building fit
(Bx, Bz) = (sizeX, sizeZ) if q mod 2 = 0 else (sizeZ, sizeX); ox = floor((Fw - Bx) / 2) + dx; oz = floor((Fd - Bz) / 2) + dz; accept iff 0 <= ox AND ox + Bx <= Fw AND 0 <= oz AND oz + Bz <= Fd AND surfaceY + sizeY - 1 <= maxBuildYA quarter turn swaps the horizontal dimensions but never rescales a voxel. Signed X and Z offsets move the centered origin. Finalization rejects any footprint crossing the protected rectangle or any declared NCM3 envelope above the configured build ceiling, even when the envelope's top layer contains no occupied voxel.
- q
- Quarter-turn count in the range zero through three.
- Fw, Fd
- Active foundation width and depth in world voxels.
- dx, dz
- Signed placement offsets stored in the BuildingManifest.
- Bx, Bz
- Rotated NCM3 footprint dimensions at exact 1:1 scale.
Finalization binds the full payload hash to an exact footprint
Rustprograms/nicechunk_building/src/lib.rs if hash_payload_slices(&payload_slices) != manifest_view.expected_hash {
return Err(NicechunkBuildingError::BuildingHashMismatch.into());
}
let dimensions = validate_ncm3_payload(&payload_slices)?;
let (footprint_width, footprint_depth) = if manifest_view.quarter_turns % 2 == 0 {
(dimensions.x, dimensions.z)
} else {
(dimensions.z, dimensions.x)
};
let max_build_y = i32::from(site.surface_y)
.checked_add(
i32::try_from(dimensions.y).map_err(|_| NicechunkBuildingError::BuildingDoesNotFit)?,
)
.and_then(|value| value.checked_sub(1))
.ok_or(NicechunkBuildingError::BuildingDoesNotFit)?;
if !building_axis_fits(site.width, footprint_width, manifest_view.offset_x)
|| !building_axis_fits(site.depth, footprint_depth, manifest_view.offset_z)
|| max_build_y > i32::from(context.config.max_build_y)
{
return Err(NicechunkBuildingError::BuildingDoesNotFit.into());
}The program reads every complete shard, hashes their ordered payload slices, parses the bounded NCM3 envelope, applies the quarter-turn footprint, and rejects a revision that does not fit before either the manifest or BuildSite becomes active.
Guardian discovery must still match the complete Building PDA
JavaScriptplay/play-chain-buildings.jsexport function buildingMatchesFoundation(building, foundation) {
const fullHash = String(building?.contentHash || "").trim().toLowerCase();
const expectedPrefix = String(foundation?.contentHash || "").trim().toLowerCase();
return String(building?.foundationId) === String(foundation?.foundationId)
&& String(building?.owner || "") === String(foundation?.owner || "")
&& Number(building?.revision) === Number(foundation?.activeRevision)
&& /^[0-9a-f]{64}$/.test(fullHash)
&& /^[0-9a-f]{32}$/.test(expectedPrefix)
&& expectedPrefix !== ZERO_BUILDING_HASH
&& fullHash.startsWith(expectedPrefix);
}The regional record contributes a 128-bit hexadecimal prefix and active BuildSite identity. The loaded Building PDA must supply the same foundation, owner, revision, and a complete 256-bit hash beginning with that prefix before it enters the verified render set.
IMPLEMENTATION EVIDENCE
Where these claims come from
Each claim is intentionally scoped to a concrete implementation path. These references are for verification, not decoration.
play/foundation-controller.js
Implements local level-ground, solid-support, fluid, clearance, overlap, hologram, and locked-anchor construction preflight.
programs/nicechunk_building/src/building.rs
Defines BuildSite, BuildingManifest, BuildingShard, Chunk coverage, exact-fit math, shard limits, SHA-256 input hashing, and the bounded NCM3 validator.
programs/nicechunk_building/src/lib.rs
Validates player sessions and PDAs, stages cross-Chunk index work, writes resumable shards, finalizes complete payloads, and atomically activates revisions.
programs/nicechunk_chunk/src/state.rs
Stores per-Chunk foundation indexes, rejects overlapping XZ rectangles, and protects only the canonical support layer.
chunk.js/ncm/blueprint-codec.js
Defines canonical declarative NCM3 commands, varint encoding, material references, and raw Building PDA payload decoding.
chunk.js/construction/building-parser.js
Parses NCM3 without executable imports, preserves one-to-one scale, applies quarter turns and integer offsets, and builds compact placements.
chunk.js/construction/building-mesher.js
Partitions verified buildings into terrain-compatible Chunks with baked light, cross-boundary face removal, greedy quads, packed buffers, visual passes, frustum bounds, and collision masks.
chunk.js/construction/building-mesh-client.js
Runs parse, placement, and meshing in a cancellable, prioritized worker queue with transferable buffers and a main-thread fallback.
play/building-controller.js
Owns exact-scale preview state, fit gating, nearest-first chain meshing, stale-work cancellation, verified collision, and bounded mesh caching.
play/play-chain-foundations.js
Verifies Guardian regional manifests against chain commitments and BuildSite identity before exposing nearby foundation records.
src/chain/nicechunkChain.js
Loads active BuildingManifest and shard PDAs, reconstructs ordered payloads, verifies complete SHA-256 values, decodes BuildSites, and submits staged foundation and building transactions.
play/play-chain-buildings.js
Filters, caches, and applies buildings whose foundation, owner, revision, and full content hash match the verified BuildSite and Guardian record prefix.
programs/nicechunk_guardian/src/state.rs
Defines the compact on-chain Guardian region revision, record count, and 16-byte manifest digest used by the discovery layer.
