SURFACE DECORATION TABLE
Cotton begins as one ordered rule bound to a grass top face
The current SurfaceDecorationTable revision contains forty-three generic numeric rows. Rule 74 maps canonical grass block 1 to cotton drop block 48, uses decoration model 12, occupies roll interval 425 through 454 for salt 201, and carries the shadow and mineable flags. Chunk.js fetches those rows for rendering; the Chunk Program reads the PDA again when it evaluates a reward.
A coordinate must first resolve an uncovered canonical grass surface inside the rule's height range. Water above the surface suppresses the decoration, and a generated tree voxel in the bound space wins instead. Rows using the same salt share one hash roll and are evaluated in stored order, so cotton and the five flower colors occupy disjoint bands rather than running six unrelated random trials.
Grass block 1 resolves cotton block 48 when the shared roll lies in [425,455).
A stable 0.3% interval among eligible grass coordinates, not a repeated swing chance.
The bundled JavaScript defaults are initialization and test fixtures, not the production authority.
ONE ATOMIC MINING ACTION
The program rechecks the support, records the break, and stores grass before cotton
A mining transaction supplies integer coordinates and the client's expected base block. The Chunk Program verifies the session and canonical accounts, rejects a foundation-protected coordinate, regenerates the base block, reads both rule PDAs, and rejects air, water, bedrock, or an expected-block mismatch. A decoration becomes eligible for the secondary reward only when its surface Y and surface block match the block being mined; a mismatch removes that extra without invalidating the base mining action.
The transaction records the broken local coordinate and then invokes the Backpack Program for the required terrain reward. Only after that strict append succeeds does it build a secondary list. Cotton is first, with block ID 48, the supporting coordinate, the same precision-gathering volume, and metadata packing rule ID 74 with decoration ID 12. An optional ResourceDropTable exploration reward follows it.
- Reconstruct
Resolve the canonical block and PDA-driven decoration for the submitted coordinate.
- Stage the mandatory state
Insert the broken coordinate and strictly append the mined support block to the owner's backpack.
- Offer ordered extras
Try cotton first and an exploration drop second without making either one a reason to fail the base mining action.
BACKPACK CAPACITY
Cotton needs compatible stack headroom or a record of its own
The backpack account physically reserves ninety-nine 80-byte records, but current initialization limits a new backpack's active capacity to at most fifty. Item count is dense: records occupy indexes zero through itemCount minus one. The strict grass append happens before the lossy batch, but it increases itemCount only when no compatible grass stack has room and a new record must be opened.
A Backpack with no free records can still retain cotton when a block-48 stack with the same category, flags, and packed rule-74/decoration-12 metadata remains below quantity ninety-nine. Conversely, headroom in an unrelated cotton identity does not help. If grass and cotton both need new records, they consume free records in that order; if grass merges, a single free record may remain for cotton. A skipped cotton candidate does not stop an exploration extra that can merge into its own compatible stack. There is no pending mailbox, later claim, or compensating mint for any candidate that cannot fit.
The account format reserves 99 records, but the initialization instruction clamps capacity to 50.
The transaction fails atomically only when the grass reward can use neither form of storage.
Cotton is attempted before the exploration extra, using its metadata-specific block-stack identity.
RECIPE 1025
Four cotton units and one dry-grass unit must match exactly
The current enabled recipe in table 222 has two block templates for order-independent matching: cotton block ID 48 with quantity four and dry-grass block ID 29 with quantity one. Its chain output is material item code 1025. The public material catalog maps that code to class fiber, forge use fabric, and render mode cloth. Plant fiber is no longer in the public material catalog; recipes 1003 and 2003 remain disabled so active identities do not shift.
Execution must also include at least one fuel index whose maximum heat tier reaches the recipe's minimum of one. Input and fuel indexes share one uniqueness set, so an index contributing dry grass to the recipe cannot also serve as fuel. A batch multiplier scales both template quantities, but the recipe still produces one material record whose volume is calculated from that output template and the batch's consumed-to-template input-volume ratio.
The chain matches packed block identifiers from authoritative backpack records.
One quantity-bearing cotton-cloth material record is appended for the current single-output recipe.
At least one unique fuel slot is required in addition to the five recipe inputs.
AUTHORITATIVE MATERIAL TRANSITION
Recipe execution consumes exact units and writes the resulting cloth
Before mutating the backpack, the Smelting Program validates its owner, capacity, every unique input and fuel index, exact quantities, heat tier, and the room available after partial or complete consumption and output insertion. It sums only the proportional input volume being consumed, excludes fuel volume, then asks the Backpack Program to consume those exact input quantities and one unit from each selected fuel stack.
For each active output, the program starts from that output's PDA template volume, scales it by batch multiplier and by the ratio of actual selected input volume to expected recipe-template input volume, then applies recipe yield and the current Smelting skill multiplier with integer arithmetic. For one default-volume cotton-cloth batch, the five-million template becomes 325,000 cubic millimetres at level zero or 487,500 at level ten. The current one-output recipe writes one cloth slot carrying that calculated batch volume.
Applied to the scaled per-output PDA template before the skill factor, using integer division.
Level zero preserves the recipe output; levels one through ten add 5% extra output each.
Partial stack updates, full removals, and output append occur inside one atomic transaction.
CLOTH INSIDE THE FORGE
The editor inherits rich material behaviour; the chain keeps a narrower aggregate proof
The forging page maps item code 1025 back to cotton cloth and asks Chunk.js for the baked cloth surface used by material swatches and the live workbench. Locally, each 14 by 10 by 14 component measures occupied cells, scales the selected slot's volume to the material actually present, multiplies that volume by density score, and uses the resulting mass weight across twelve attributes. Restored equipment rebuilds encoded geometry and RGB444 colors, then uses its cloth identity for wind motion; it does not retain the workbench material tile. Cloth painting and runtime flutter are presentation and design behaviour, not a chain simulation of fabric.
Forge submission takes whole selected material slots. The Backpack Program verifies that every index is a valid material, rejects duplicates, and checks selected volume, effective durability, and validated mass against the three NCF1 requirements. It then creates an immutable ForgedItem PDA containing the complete NCF1 bytes, consumes all selected slots, and appends one forged record pointing to that account. Neither account preserves the full input list, exact cloth provenance, or dye-to-paint relationship; the Backpack record keeps NCF1-derived volume and mass plus material-derived outcome fields and the 32-bit design hash.
Five flower-dye recipes are enabled, but the current verified world path has no native way to collect water block 17: water is unmineable, rule tables reject water drops, and no bucket instruction exists. The page therefore treats dye as an available recipe definition, not a complete world-harvest-to-dye loop.
Used volume follows occupied component cells before density-weighted inheritance.
The current verifier checks three aggregate capacities across whole selected slots.
A verified native source for required water block 17 is not currently implemented.
DROP, CAPACITY, AND YIELD MATH
One fixed hash chooses the plant; ordered slots decide whether the reward survives
The first equation scopes cotton to eligible grass coordinates. The second models the strict base reward and ordered lossy extras. The third mirrors recipe 1025's exact input counts, per-output PDA volume baseline, selected-input ratio, and two-stage integer yield.
Cotton's deterministic rule interval
H = surfaceHeight(x,z); r = hashCoord3(seed,x,H+1,z,1200+201) mod 10000; cotton iff surfaceBlock=grass AND (waterLevel is null OR waterLevel<=H) AND treeBlock(x,H+1,z)=air AND 425<=r<455; P_roll(cotton | eligible grass) = (455-425)/10000 = 0.003Rule 74 occupies thirty values in the shared ten-thousand-value band for salt 201. The 0.3% figure is the conditional hash share for an otherwise eligible grass face; it is not a fresh random chance per swing and not a percentage of every world block.
- H
- Canonical generated surface height at horizontal coordinate x,z.
- r
- Stable unsigned rule roll shared by rows using salt 201 at this coordinate.
- 425 <= r < 455
- The half-open interval assigned to cotton in the current revision-2 table.
Strict support reward, then ordered stack-aware lossy extras
S1 = strictStore(S0,grass); A_cotton = D*canStore(S1,cotton[block=48,metadata=(74<<16)|12]); S2 = A_cotton ? store(S1,cotton) : S1; A_extra = E*canStore(S2,extra[block=dropId,metadata=0]); S_after = A_extra ? store(S2,extra) : S2The mandatory grass reward first merges into compatible headroom or opens a record; if neither is possible, the whole transaction fails. D and E indicate an eligible cotton decoration and exploration extra. The lossy batch then attempts cotton and extra in order against the evolving Backpack state. Each may merge without increasing itemCount, each is skipped independently when it cannot fit, and failure of the cotton attempt does not stop the later extra attempt.
- S0, S1, S2, S_after
- Backpack state before the base reward, after strict grass, after the cotton attempt, and after the exploration-extra attempt.
- D, E
- Binary indicators for an eligible surface decoration and exploration extra.
- A_cotton, A_extra
- Whether each secondary candidate has matching stack headroom or can open a new record when its turn is evaluated.
Cotton-cloth inputs and per-output integer volume
N_cotton=4m; N_dryGrass=m; N_fuel>=1; inputIndexes intersect fuelIndexes = empty; b_skill=min(15000,10000+500L); V_expected=max(1,m*V_recipe); V_scaled=floor(max(1,V_template)*m*max(1,V_in)/V_expected); V_cloth=max(1,min(2^32-1,floor(floor(V_scaled*650/10000)*b_skill/10000)))Batch multiplier m scales the quantities in recipe 1025's cotton and dry-grass templates, while every input and fuel index must remain unique. Fuel volume is not part of V_in. The program first scales this output's five-million-cubic-millimetre PDA template by the ratio between consumed and recipe-template input volume, then applies the 650-basis-point recipe yield and the 10,000-to-15,000 skill multiplier with integer division. It does not divide one aggregate result evenly among outputs.
- m
- Recipe batch multiplier; one batch consumes four cotton units and one dry-grass unit from unique selected indexes.
- L
- Current smelting level from zero through ten.
- V_recipe, V_template, V_in, V_cloth
- One batch's expected recipe-input volume, this output's PDA template volume, selected recipe-input volume, and the resulting cloth-record volume in cubic millimetres.
Every secondary reward write validates the backpack owner
Rustprograms/nicechunk_backpack/src/state.rs Self::validate_owner(data, owner)?;Owner validation is the stable boundary shared by every lossy reward implementation. In v4, the remaining routine evaluates optional rewards in order, fills matching 99-unit block-stack headroom first, skips only units that still do not fit, and updates aggregate mass only for stored units.
Verified inputs and every output are checked before Backpack mutation
Rustprograms/nicechunk_smelting/src/lib.rs let validated_inputs = {
let backpack_data = backpack.try_borrow_data()?;
BackpackAccountView::validate_recipe_inputs(
&backpack_data,
owner.key,
indexes,
fuel_indexes,
&recipe,
multiplier,
)?
};
let recipe_input_volume_mm3 = recipe_input_volume_mm3(&recipe);
let mut output_volumes_mm3 = [0_u32; state::RECIPE_MAX_OUTPUTS];
let mut output_quantities = [0_u32; state::RECIPE_MAX_OUTPUTS];
for output_index in 0..recipe.output_count as usize {
let output = &recipe.outputs[output_index];
output_volumes_mm3[output_index] = smelting_recipe_output_volume_mm3(
&recipe,
output,
validated_inputs.input_volume_mm3,
recipe_input_volume_mm3,
multiplier,
skill_output_bps,
)?;
output_quantities[output_index] = smelting_output_quantity(
&recipe,
output,
validated_inputs.consumed_input_units,
multiplier,
skill_output_bps,
)?;
}
consume_backpack_resources(
program_id,
smelting_authority,
owner,
backpack,
backpack_program,
material_physics,
indexes,
fuel_indexes,
&validated_inputs.consumption_quantities,
)?;Validation first reads the authoritative Backpack and calculates exact per-slot input quantities. The program then computes every active output's checked volume and quantity into fixed arrays. Only after all those fallible calculations succeed does it consume the exact input quantities plus one unit from each selected fuel stack; later append or progress failure still rolls the complete Solana transaction back.
Chunk.js weights inherited attributes by material actually used
JavaScriptchunk.js/forge/forge-workbench.js inputVolumeMm3 = checkedSafeAdd(inputVolumeMm3, material.volumeMm3, "total forge input volume");
const componentSolidCells = forgeSolidCellCount(component.solid);
componentSolidCellCounts[index] = componentSolidCells;
solidCellCount += componentSolidCells;
const componentVolumeMm3 = Math.floor(material.volumeMm3 * componentSolidCells / FORGE_WORKBENCH_SOLID_CELL_COUNT);
componentVolumesMm3[index] = componentVolumeMm3;
usedVolumeMm3 = checkedSafeAdd(usedVolumeMm3, componentVolumeMm3, "used forge material volume");
// With integer kg/m3 and mm3 inputs, this product is an exact microgram
// count. The public density ceiling keeps the 24-component total inside
// Number's safe-integer range; BigInt below preserves exact score weights.
const massWeight = componentVolumeMm3 * material.profile.densityKgM3;
componentMassWeights[index] = massWeight;
massWeightTotal = checkedSafeAdd(massWeightTotal, massWeight, "forge material mass weight");
for (let attributeIndex = 0; attributeIndex < FORGE_ATTRIBUTE_KEYS.length; attributeIndex += 1) {
const key = FORGE_ATTRIBUTE_KEYS[attributeIndex];
attributeTotals[attributeIndex] += BigInt(material.profile.attributes[key]) * BigInt(massWeight);The local workbench derives twelve design attributes from occupied component cells and density-weighted used volume. This detailed inheritance explains the editor and exported design, but the chain stores only aggregate forge outcome fields and a 32-bit design hash.
IMPLEMENTATION EVIDENCE
Where these claims come from
Each claim is intentionally scoped to a concrete implementation path. These references are for verification, not decoration.
chunk.js/world/surface-decoration-rules.js
Defines the current cotton and five-color flower fixture rows, disjoint basis-point bands, flags, and generic rule compiler used by Chunk.js initialization and tests.
programs/nicechunk_chunk/src/state.rs
Validates the deployed SurfaceDecorationTable format and mirrors the stable hash, water, tree, surface, height, salt, and ordered interval matching.
programs/nicechunk_chunk/src/lib.rs
Shows canonical mining validation, strict support-block storage, cotton metadata packing, and decoration-before-exploration secondary reward ordering.
programs/nicechunk_backpack/src/state.rs
Implements strict and lossy backpack appends, exact Smelting stack consumption, dense capacity accounting, whole-slot forge consumption, and aggregate forge material checks.
src/data/smeltingRules.js
Publishes cotton cloth as four cotton plus one dry grass, item and recipe code 1025, fiber yield, cloth rendering mode, and twelve base attributes.
scripts/sync-smelting-recipes.ts
Encodes one quantity-bearing RecipeTable template per raw or material requirement and keeps disabled plant-fiber recipe identities inactive.
programs/nicechunk_smelting/src/state.rs
Allocates exact recipe quantities from unique input indexes, validates fuel indexes, projects Backpack output capacity after partial consumption, checks heat tier and packed block identifiers, and derives skill output basis points.
programs/nicechunk_smelting/src/lib.rs
Consumes validated recipe quantities and one unit per fuel index, calculates bounded output volume and quantity, appends material output, and awards Smelting progress atomically.
chunk.js/forge/forge-workbench.js
Calculates used component volume and density-mass-weighted local attribute inheritance for the NCF1 workbench.
forging/chain-adapter.js
Maps authoritative backpack material slots into the forge UI while filtering the retired plant-fiber item identity.
tests/smelting_rules.ts
Locks cotton and flower block IDs, exact cotton-cloth inputs, material output identity and volume template, dye inputs, and plant-fiber retirement.
